– Overview –
The HE503CU-GR is a 20mm micro sight designed for rifle and carbine applications. HE503CU-GR features Holosun’s Solar Failsafe technology and our Multi-Reticle System (MRS) which includes a 2MOA dot and a 65 MOA Circle. Holosun’s Green Super LED allows for up to 50k hour battery life with 10 daylight and 2 night vision compatible reticle intensity settings.
The HE503CU-GR housing is made from 6061 aluminum and includes both a lower 1/3 co-witness mount (1.63”) and a low mount (.75”) for low-comb height rifle applications. Additional features include Shake Awake technology, rubber lens covers, and a side battery for the 2032 battery. HE503CU-GR is a versatile sight for users of all levels.
Items Dimensions (in inches)
In the Box
- Lower 1/3 Cowitness Mount
- Low Profile Mount
- T10 L Key
- Rubber Cover
- User Manual
- CR2032 Battery
- Lens Cloth
– TECH & FEATURES –
-
Solar Failsafe™ -
Shake Awake™ -
Multiple Reticle System -
Super LED -
Multilayer Reflective Glass
Solar Failsafe™
Solar Failsafe Technology is one of many innovations featured on solar-equipped Holosun optics. With Solar Failsafe, if your battery fails you always have a backup power source when natural or artificial light is available. Solar Failsafe is activated while in Auto Mode where reticle intensity is automatically adjusted based on the amount of light the solar cell receives. In brighter conditions you have a brighter reticle and in lower-light conditions the reticle will step down in intensity to match any lighting conditions. On models equipped with a super capacitor, it is possible to run the optic, indefinitely, in daytime and night conditions, by maintaining a charge through the Solar Failsafe System all without a battery.
– Specification –
- Green MRS:2 MOA Dot; 2 MOA Dot & 65 MOA Circle
- Up to 50,000 Hours Battery Life (Setting 6)
- 12 Brightness Setting: 10 DL & 2 NV Compatible
- Convenient Tray Battery Compartment
- Parallax-free & Unlimited Eye Relief
PHYSICAL SPECS
| Window Size | 20mm Diameter |
| Dimension (in) | 2.6×1.43×1.6 |
| Weight (oz) | 3 |
MECHANICAL SPECS
| Housing Material | 6061 T6 Aluminum |
| Surface Finish | MAO |
| Adjustment per Click | 0.5 MOA |
| W&E Travel Range | ±50 MOA |
ENVIRONMENT SPECS
| Storage Temperature | -40℃~70℃ |
| Working Temperature | -30℃~60℃ |
| Submersion | IP67 |
| Vibration | 1000G |
| Weight | .8 kg |
|---|---|
| Dimensions | 25 × 25 × 10 cm |
