ThermTec Vidar 660 Thermal Scope
The ThermTec Vidar 660 Thermal Scope is at the forefront of thermal imaging technology, designed to meet the demands of both close and long-range scenarios with exceptional clarity and precision. Its dual-field of view system and advanced features make it an ideal choice for a variety of applications, from security and hunting to industrial use.
Key Features of ThermTec Vidar 660
- Dual-Field of View:
- Wide FOV: 20mm objective lens with a 21.7° x 17.4° field of view for broad scene observation.
- Narrow FOV: 60mm objective lens with a 7.3° x 5.9° field of view for detailed target identification.
- Highly Sensitive Detector:
- Equipped with a thermal imaging sensor featuring NETD ≤25mK and a 12µm pixel size, ensuring superior detail recognition and imaging quality.
- Non-Shutter Correction Technology:
- Utilizes invisible background calibration to prevent screen freezes and eliminate noisy shutter sounds.
- Laser Rangefinder with Ballistic Calculator:
- Enables precise long-range target measurement and accurate shooting calculations.
- Automatic Zeroing:
- Simplifies the adjustment of the reticle, ensuring accurate targeting with minimal effort.
- Recoil Activated Video (RAV):
- Records video before, during, and after your shot, capturing critical moments of your shooting experience.
- Long Detection Range:
- Features a maximum detection range of up to 3,000 meters in complete darkness, enhanced by the advanced imaging algorithm.
- Lightweight & Compact Design:
- Designed for portability and ease of use, making it a practical choice for various field conditions.
Specifications of ThermTec Vidar 660
- Sensor Parameters:
- Sensor Resolution: 640 × 512
- Pixel Size: 12µm
- NETD: ≤25mK
- Frame Rate: 50Hz
- Lens Parameters:
- Lens Size: 20mm / 60mm
- Field of View (FOV): 21.7° x 17.4° (wide) / 7.3° x 5.9° (narrow)
- Magnification: 1.1x / 3.2x
- Digital Zoom: 1.0-5.0x
- Color Palette: 6 options
- Detection Range: Up to 3,000 meters
- Screen Parameters:
- Type: OLED
- Resolution: 1024 × 768
- Size: 0.39 inch
- Battery Parameters:
- Battery Type: 18650 x 2
- Battery Life: 10 hours
- Physical Parameters:
- Photo/Video Playback: Yes
- Memory: 64GB built-in
- IP Protection: IP67
- Auto/Manual Zeroing: Yes
- Picture-in-Picture: Yes
- Dimensions: 220mm × 100mm × 87mm
- Weight: 920g
Enhance your thermal imaging capabilities with the ThermTec Vidar 660, a cutting-edge tool designed for professionals who require the highest level of performance and precision.
