ThermTec Wild 635 LRF Thermal Imaging Camera
The ThermTec Wild 635L is a high-performance thermal monocular designed for a range of applications including surveillance, hunting, and search and rescue. With its advanced optical and sensor technology, it delivers exceptional thermal imaging quality and versatility.
Key Features of ThermTec Wild 635 LRF
- High-Quality Lens: Equipped with a 35mm f/0.8 lens, the Wild 635L captures detailed thermal radiation with a broad field of view of 12.5 x 10 degrees.
- Advanced Sensor: The monocular features an uncooled 12µm 640 x 512 pixel sensor with a 50Hz refresh rate, providing sharp and responsive imaging.
- Low NETD: With a Noise Equivalent Temperature Difference (NETD) of <18mK, the Wild 635L excels in detecting even the smallest temperature differences.
- Digital Zoom: Offers a 4x digital zoom to magnify and analyze details in the thermal image.
- Durable Construction: Rated IP67 for dust and water resistance, and built to withstand harsh conditions with operating temperatures ranging from -20°C to 50°C.
- User-Friendly Design: Features a one-finger focusing wheel and joystick navigation for easy operation, and a magnesium alloy housing for durability.
Specifications ThermTec Wild 635 LRF
- Lens: 35 mm
- F-ratio: 0.8
- Diopter Adjustment: -5 to +5
- Eye Relief Distance: 40 mm
- Exit Pupil Diameter: 6 mm
- Optical Zoom: 2x
- Digital Zoom: 4x
- Field of View (h/v): 12.5° / 10°
- Thermal Type: Uncooled
- Sensor Resolution (h/v): 640 pixels / 512 pixels
- Pixel Pitch: 12 µm
- Sensitivity: 18 mK
- Spectral Range: 8 µm / 14 µm
- Display Resolution (h/v): 1024 pixels / 768 pixels
- Refresh Rate: 50 Hz
- Image Polarity: White Hot, Black Hot, Golden, Red, Green, Violet
- Output Screen Color: Full color
- Startup Time: 3 seconds
- Package Contents: User manual, lanyard, hand strap, protective pouch, lens cloth, charger, 18650 battery (x2)
- LRF Range: 1000m (±1m)
DRI Ranges
- Detection: The ability to detect an object’s presence.
- Recognition: Identifying the type of object (e.g., person, vehicle, airplane).
- Identification: Determining specific details (e.g., distinguishing friend from foe).
Object | Detection Distance | Recognition Distance | Identification Distance |
---|---|---|---|
Rabbit | 525 meters | 131 meters | 65 meters |
Person | 1847 meters | 461 meters | 230 meters |
Vehicle | 4472 meters | 1118 meters | 559 meters |
Conclusion
The ThermTec Wild 635L is a robust and feature-rich thermal monocular that offers high-resolution imaging, extensive field of view, and advanced digital capabilities. Its rugged build and user-friendly design make it an excellent choice for professionals and enthusiasts who require reliable thermal imaging performance in various environments.
